Advanced One-Piece Spindle Solution for Steel Rolling Mills

Home » project » Steel » Advanced One-Piece Spindle Solution for Steel Rolling Mills

ABS and ACB redesigned a spindle solution for steel rolling mills using a one-piece configuration and split cylindrical roller bearing technology, improving reliability and reducing maintenance downtime.

USA
ABS, ACB
One-piece spindle with split cylindrical roller bearing solution for steel rolling mills

Download the project: Access the project in PDF format

ABS and ACB has redesigned a Spindle Solution to improve reliability in steel rolling mills, based on a one-piece design and split cylindrical roller bearing technology.

  • Sector: Steel Industry
  • Equipment: Steel Rolling Mill
  • Criticality: High — critical asset where spindle performance directly impacts production continuity and maintenance efficiency, addressed through an application-driven redesign.
  • Key Factors: One-piece spindle design — eliminating failure-prone joints | Split cylindrical roller bearing and housing — increased load capacity and simplified maintenance | FEA-validated engineering and high-strength alloy steel — optimized stress distribution and fatigue resistance | Proven operational reliability — failure-free operation extended from 3 months to over 12 months | Scalable solution — planned implementation across 16 rolling mill stands

Integrated spindle solution combining one-piece design and split cylindrical roller bearing technology

Advanced one-piece Spindle solution for steel rolling mills | ABS & ACB Custom Bearings

Engineering Brief: The context

Exploded view of spindle assembly with split cylindrical roller bearing and housing

Spindles are critical components in rolling mills, responsible for transmitting torque and motion from the drive system to the work rolls. Their proper operation is essential to ensure the performance of the rolling process. In this context, ABS was engaged to analyze a 90 t/h rolling mill in Colombia that was experiencing recurring spindle failures in its mill stands, leading to misalignment, wear, and frequent downtime.

The original system consisted of a two-piece spindle with a splined joint and bolted connections, supported by a solid ball bearing. This configuration created multiple failure points and limited overall system reliability. To address these limitations, ABS designed a one-piece spindle supported by a split cylindrical roller bearing and split housing.

The new configuration provides higher load capacity, extending component service life. In addition, the split bearing and housing design simplifies assembly and maintenance, reducing intervention time and contributing to a more reliable, efficient, and durable system.

The Challenge

Before developing our solution, the existing system faced several technical issues and limitations that significantly affected performance and reliability. The main problems identified were:

  • Failure of coupling bolts
  • Wear of bearing seat
  • Spline tooth failure
  • Wear of splined joint
  • Misalignment of universal joints
  • Wear of Teflon bushings
  • Wear of coupling plates

Before the Redesign

Worn spindle components showing damage and misalignment in rolling mill

The ABS Solution

To overcome the limitations of the existing system, we implemented a complete redesign of the spindle and its support assembly. Our solution focused on three key areas:

Aquí tienes el texto extraído:


Redesign of components:
We replaced the original two-piece spindle with a one-piece design, eliminating the splined joint and bolted connections that were prone to failure. This improvement enhances structural integrity and ensures more efficient power transmission to the work rolls.

Applied innovations:
Instead of a solid ball bearing and housing, we incorporated a split cylindrical roller bearing with a split housing. This solution increases load capacity, reduces stress concentration and premature wear, and simplifies installation and disassembly, making maintenance faster and more efficient.

Key technologies:
By combining cylindrical roller bearing technology with a split housing design, we achieved higher durability, improved alignment, and easier access during servicing. These advancements extend the service life of critical components while minimizing downtime and maintenance costs.

Technical drawing comparing the original two-piece rolling mill spindle with the ACB redesigned one-piece spindle featuring a split cylindrical roller bearing and housing.
Split cylindrical roller bearing for steel rolling mill spindle applications
One-piece spindle for steel rolling mills eliminating failure-prone joints
Split bearing housing for steel rolling mill spindle system

Engineering Highlights

Developing this solution required a rigorous engineering approach to ensure reliability and performance under demanding rolling mill conditions. Our work focused on the following key aspects:

  • Stress analysis and simulations: We conducted Finite Element Analysis (FEA) to identify critical stress zones, confirming that the one-piece spindle reduces stress concentrations and improves load distribution. Calculations also verified the superior load capacity of cylindrical roller bearings.
  • Materials and configurations: We used high-strength alloy steel for greater fatigue resistance and durability. The split bearing and housing were designed for precise alignment and efficient load transfer under heavy conditions.
  • Structural and maintenance improvements: The one-piece spindle removes failure-prone joints, while the split bearing and housing design minimize downtime, enhance durability, and reduce maintenance costs.
Quality inspection and on-site assembly of a custom-engineered rolling mill spindle with split cylindrical roller bearing and housing.

Operational Benefits

The implementation of the redesigned spindle and bearing system delivers measurable improvements.

Increased reliability: A one-piece spindle design and roller bearing technology reduces failure points and enhances overall system robustness.

Lower maintenance costs: The split bearing and housing simplify assembly and disassembly, reducing labor hours and spare part consumption.

Higher equipment availability: Faster maintenance and fewer unexpected failures minimize downtime, ensuring continuous production.

Extended service life: Improved load capacity and optimized material selection extend the lifespan of critical components.

Spindle solution designed to improve reliability in steel rolling mills

ABS and ACB: a trusted engineering partner for the Steel industry

The implemented solution increased failure-free operating time from 3 months to more than one year, and the system remains in service. It has also simplified maintenance operations, significantly reducing associated costs and equipment downtime. Following the success of the project, the decision was made to implement the solution across all 16 rolling mill stands, with the objective of improving operational reliability, increasing equipment availability, and reducing maintenance-related costs.

The project demonstrates the value of ABS and ACB’s application-driven engineering approach, where design, materials, and component selection are adapted to the specific requirements of each application. By combining ABS engineering expertise with ACB’s custom bearing capabilities, the Group delivers engineered solutions for critical power transmission systems in demanding steel industry applications.

ABS and ACB custom-engineered one-piece spindle installed in a steel rolling mill, featuring a split cylindrical roller bearing and housing.
